INSTALL on radiators farther from the boiler and in cold rooms, (for example on second floor radiators.), 1/8" connection. VENTING CAPACITY . . . Equal to 8 ordinary type air valves.
INSTALL on radiators farthest from the boiler, and in coldest rooms, (for example on third floor radiators.), 1/8" connection. VENTING CAPACITY . . . Equal to 15 ordinary type air valves.
The Amtrol EXTROL EX-30 hydronic expansion tank is designed for closed-loop heating systems to control pressure buildup as system water expands and contracts.
4.4 gallon tank volume
2.5 gallon maximum acceptance volume
1/2 in. NPT male system connection
12 PSI factory precharge
100 PSI maximum working pressure
240°F maximum operating temperature
Heavy-duty Butyl/EPDM diaphragm
High-strength steel construction
7-year limited warranty
Manufacturer part number: 389710. Model: EX-30.
INSTALL where a large amount of air must be vented (NOT TO BE USED ON HAND FIRED SYSTEMS UNLESS RADIATOR SUPPLY VALVES ARE LEFT ON ALL THE TIME.), 1/8" connection. VENTING CAPACITY ... Equal to 27 ordinary type air valves.
INSTALL where a large amount of air must be vented (NOT TO BE USED ON HAND FIRED SYSTEMS UNLESS RADIATOR SUPPLY VALVES ARE LEFT ON ALL THE TIME.), 1/8" connection. VENTING CAPACITY ... Equal to 27 ordinary type air valves.
